Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights

Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights Featured Image
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights
  • Mini LED Recessed Spot Light in the Ceiling or Wall, Flush Mount the LED Puck / Under Cabinet Lights

Short Description:

LED Mini recessed spotlight use Bridgelux LED chip control, CRI(color rendering index) 80, features 360° rotation and adjustable directional 45°and narrow beam 60°,and to choose other color black,silver,and Plating chrome / gold.



Mount Hole Size: diameter size about 1-3 inch, and you can cutting hole in the ceiling or wall and then inserting the fixture into the opening.
Supply Power: choose constant current and constant voltage to provide a routine work driver. here provide 12V and 1*3w power, or you can choose local market to shopping transformer ( to convert the high voltage to the low voltage device).
Retention Clips:Spring-Loaded retention clips secure the fixture against the ceiling.



Product Model:CHIA7257-3W
Adjustable Directional : 45°
Luminous flux:245 Lm Work


Download as PDF

Product Detail

PRODUCT PARAMETER

Product Tags

recessed spot light7257 recessed spot light7257-3WCHIA7255-3W_04‘

CHIA7257-3W_06 CHIA7257-3W-详情2英文_02 CHIA7257-3W-详情2英文_04 CHIA7257-3W-详情2英文_05

  • Previous:
  • Next:
    • Model CHIA7257-3W
    Rated Power 3 W
    LED Light Source COB
    LED Chip Bridgelux LED chip
    Color Temperature(CCT) 3000k,4000k,6000k
    Light Pole Sizes Optional
    Body Color Customized
    Input voltage 12V/24V
    Color Rendering Index(Ra) >=80
    Light Fixture Material Aviation Aluminium
    Luminous flux 245 Lm
    Work Time(Hour) 20000
    Light Beam Angle(Degree) 60°
    Warranty (Year) 3
