LED Shoebox Street light Twist Lock Photocontroller and All in One Customize Different Voltage and Waterproof Rating

Short Description:

1. Product Model: JL-205
2. Rated Voltage: 110-120 / 220-240 / 110-277 VAC
3. On / OFF Lux Level: 6 Lx on; 50 Lx off
4. IP Rating: IP54, IP65, IP67
5. Compliant Standard: CE, ROHS, UL


Product Description

Product Specification

Get Detailed Prices

Product Tags

The Photocontroller JL-205 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.

Feature
1. ANSI C136.10-1996 Twist Lock.
2. Time Delay of 3-20 seconds.
3. Surge Arrester Built-In.
4. Fail-On Mode.
5. All in One Customize Different Voltage and Waterproof Rating.


  • Previous:
  • Next:

  • Mode JL-205A JL-205B JL-205C
    Rated Voltage 110-120VAC 220-240VAC 208VAC
    Applicable Voltage Range 100-140VAC 200-260VAC 105-305VAC
    Rated Frequency 50/60Hz
    Rated loading 1000W Tungsten, 1800VA Ballast
    Power Consumption 1.5VA[3VA for HP]
    On/off level 6 lx, 50 lx
    Enclosure Color gray,maroon,blue,and available customize your requirement
    Ambient Temperature -40℃-70℃
    Related Humidity 99%
    Weight Approx 85grs
