Custom JL-205 Series Twist Lock Photocontrol and JL-210K Receptacle 110-227VAC

Short Description:

1. Product Model: JL-205C
2. Rated Voltage: 110-277 VAC
3. On / OFF Lux Level: 6 Lx on; 50 Lx off
4. Optional Accessories: JL-210K
5. Optional Custom printing
6. IP Rating: IP54, IP65, IP67
7. Compliant Standard: CE, ROHS, UL


Product Description

Product Specification

Get Detailed Prices

Product Tags

The photocontroller JL-205 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.

Feature
1. ANSI C136.10-1996 Twist Lock.
2. Time Delay of 3-20 seconds.
3. Surge Arrester Built-In.
4. Fail-On Mode.
6. JL-210K available custom
7. Photocontrol Shell by according your requirement customized.
8. Enclosure Color: black, gray, blue, orange etc


  • Previous:
  • Next:

  • Model JL-205A JL-205B JL-205C
    Rated Voltage 110-120VAC 220-240VAC 110-277VAC
    Applicable Voltage Range 100-140VAC 200-260VAC 105-305VAC
    Rated Frequency 50/60Hz
    Road Loading 1000W Tungsten 1800VA Ballast
    Power consumption 1.5VA[3VA for High Power]
    Operate Level 6Lx turn on, 50 turn off
    Ambient temperature -40~70℃
    Enclosure Color black, gray, green, blue, orange etc
    Overall sizes 84(Dia)*66mm
    Weight Approx 85 grsc
