JL-217C Outdoor Street Light Accessories Twist Lock Photocell Switch

Short Description:

1. Product Model: JL-217C
2. Rated Voltage: 120-277VAC
3. On / OFF Lux Level: 16 Lx on; 24 Lx off
4. IP Rating: IP54, IP65, IP67
5. Compliant Standard: CE, ROHS, UL


Product Description

Product Specification

Accessories

Get Detailed Prices

Product Tags

The Photocell Sensor JL-217 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.

1. ANSI C136.10-2010 Twist Lock
2. Multi-Volts Application
3. Fully Customization Available
4. Surge Arrester Built-In
5. IR filtered Photodiode Sensor
6. MOV: 6KV/3KA
7. Fail-On / Fail-Off Modes Available


  • Previous:
  • Next:

  • Product Model

    JL-217C

    Rated Voltage

    120-277VAC

    Applicable Voltage Range

    110-305VAC

    Rated Frequency

    50/60Hz

    Rated Loading

    1000W Tungsten, 1800VA Ballast, 5A e-Ballast

    Power Consumption

    0.9W Max

    Surge Immunity

    IEC61000-4-5, Class A

    Differential-Mode

    6kV/3kA

    Typical On/Off Level

    16Lx On / 24Lx Off

    Ambient Temp

    -40℃ ~ +70℃

    Related Humidity

     99%

    Overall Size

    84(Dia.) x 66mm

    Weight Approx.

    160g
